This is a low-cost (only $10 for Chinese electronics parts) modification of EggBot, printable 3D printers that accept large. Links Youtube Video First Launch Github Original EggBot CAD Assembly kits You can buy a complete assembly kit - this. The list of parts to print

1 x 0000001. Case_Bottom 1 x 0000002. Case_Top 1 x 0000003. Logo 2 x 0000004. M5_Nut_Holder 1 x 0000005. Axis_R 1 x 0000006. Spring_Holder 1 x 0000007. Axis_R_Holder 1 x 0000008. Axis_R_Lock 2 x 0000009. М5_Bolt_Holder_Bottom 2 x 0000010. М5_Bolt_Holder_Top 1 x 0000011. Axis_L_Holder 1 x 0000012. Axis_L 1 x 0000013. Hand_Holder 1 x 0000014. Hand_Holder_Guide 1 x 0000015. Hand_Holder_Guide_Case 1 x 0000016. Hand_H 1 x 0000017. Hand_V 1 x 0000018. Case_Right Non-printable parts 2 x 608zz Bearing 1 x 24mm Silicone or Rubber Gasket 1 x 15mm Silicone or Rubber Gasket Screws&Nuts 1 x Spring Diameter 9-15mm Length 17-20mm 1 x 2x18mm Iron Nail without a hat or Rivet 2 x M5x20 Bolt 2 x M5 Nut 8 x M3x10 Screw 5 x M3x16 Screw 12 x M3 Nut 4 x M3 Washer 12 x M2x5 Screw Electronics 1 x Arduino UNO 2 x 28byj-48-5v Stepper Motor + ULN2003 Stepper Motor Driver Board 1 x SG90 Micro Servo 1 x USB Cable for connect to PC A few wires Assembly

Video Assembly Instructions Assembly Instructions PDF Assembly in 3D Assembled Egg Painter Firmware As the firmware used Eggduino. It's arduino firmware for EggBot / Spherebot with Inkscape-Integration (Github). For Installation: 1) Download and unzip Firmware.zip. 2) For UNO board with CH340G download and install driver: http://www.wch.cn/download/CH341SER_ZIP.html. 3) Download the ARDUINO IDE and install it. 4) Run the software. Select the Arduino UNO board and the proper COM PORT (should be COM5 or so) in the menu "Tools->Board"… 5) Open Eggduino.ino from Firmware.zip and upload the Eggduino code to your Arudino Uno. Controlling program As the controlling program used Inkscape software. 1) Download and unzip the Inkscape software Software_inkscape+extension.zip. 2) EggBot Control Extension already included in the Inkscape from Software_inkscape+extension.zip. 3) Run the software. The EggBot Control extension for Inkscape is the tool that you will use to help you test and align the EggBot, as well as transfer your drawings to an egg. Once Inkscape is running, you’ll have an Extensions menu, and on that menu will be a submenu labeled Eggbot. If the Inkscape does not connect to the device, please check name of your Arduino in to device manager. And change it in ebb_serial.py on line 52 instead of "USB-SERIAL CH340". Use template EggBot (File->New from Template) for your drawing.
